YB-500IN, Solenoid Bolt Lock
Please Ask
YB-500IN, Solenoid Bolt Lock
- Stock Status: Please Ask
- Brand: YLI
- Model: YB-500IN
- Weight: 1.20kg
- Dimensions: 37.00mm x 185.00mm x 55.00mm
- SKU: YB-500IN
- HS CODE: 83014090
- MPN: YB-500IN
YB-500IN, Solenoid Bolt Lock
YB-500I N(LED) is an all-metal construction electric bolt .suitable for narrow frame doors which is possess with Double protection for loading current. The bolt is made of 304 stainless steel solid bar with 1000kg holding force and anti-burglar design. It contains the design of magnetic valve, particular photoelectric control structure.
Technical Parameters
| Product Parameter | Parameter Description |
| Feature | Fail Safe |
| Face Plate | 185Lx25.7Wx37H(mm) |
| Bolt | 16(length)*12.7(diameter)(mm) |
| Voltage | DC12V |
| Start Current | 960mA |
| Standby Current | 180mA |
| Solid Bolt | polishing housing, 1000Kg Holding Force |
| Suitable For | Electric Bolt For Narrow Door |
| Signal Output | Door status Output,NO/COM |
| Surface Temp | Low Temperature |
| Induction Distance | 8mm |
| LED | Light on indicates locked, light off indicates unlocked |
| Special Designed | Tested to 500000 operations |
| Face place material | Stainless Steel |
| Weight | 1.2kg |
Advantages
- Low Temperature, safe & Durable.
- Low Power, Environmental Protection.
- Special photoelectricity control,three steps current application.
- Long Life with 500000 cycles.
- MOV Provides Reverse Current Protection.
- Superior Strength Aluminium Alloy,Solid Stainless Steel Bolt.
- Autolock Time Delay: 0,3,6,9sec.
- Door statue signal output contact(NC.COM).
- Double protection for loading current.
- Auto-relock if no Action within 5 secs.
- Certificate:CE&MA.
- Photoelectricity Control,Low Temperature，
- A:The Low Current is Changed immediately;
- B:When door frame doesn`t coincide with door leaf ,door leaf against the bolt,then the electric bolt will start the low-power function to bring low temperature.
- C:The Photoelectricity Control Technology,prevent the machanical defect.
Installations
Dimensions
