PNM-9000QB 2MP x 4CH Remote Head Camera

PNM-9000QB 2MP x 4CH Remote Head Camera

PNM-9000QB is a network camera that supports 4 lens modules and 2MP resolution in each lens module. Where you want to view the same area from different angles, the PNM-9000QB is the ideal camera. It has a structure that you can install a 4-camera system with a single box. With SD memory card slots supporting 1/2 terabyte storage, the system can be set up without the need for a recorder.

Detachable lens module heads of the camera are connected to the main unit via an RJ-12 connector. The RJ-12 connector and cables come with the lens module. Each lens module can be mounted 3m away from the main unit.

When used with a recorder, each lens module can be introduced to the system as a separate channel. Power input with 12VDC and PoE + support also offers options in terms of supply.

Multi-head solution is cost effective compared to typical network cameras. Users can integrate 4CH remote head lens modules on a single body and monitor up to 4 different areas.

Selectable lens modules:

SLA-T4680A / T4680VA: 4.6mm Fixed Iris Lens

 SLA-T2480A / T2480VA: 2.4mm Fixed Iris Lens

 SLA-T1080FA: 1.6mm Fixed Iris Lens

Key Features

• 2MP x 4CH
• HDMI - Single/Quad view support
• WDR 120dB, WiseStreamII
• Defocus detection, directional detection, motion detection etc
• Max 30fps@2MP
• H.265, H.264, MJPEG
• Compatible with SLA-T4680A/T4680VA, SLA-T2480A/T2480VA, SLA-T1080FA
